Jordfeilaut. 25A 3p+N/C A-type mRB4-25/3N/C/01-A
Product number
1654851
mBR4-25/3N/C/01-A
20-25 Ampèr 4 pol/4moduler jordfeilbryter. Tilpasset samme samleskinne som elementautomat. Tiltrkkningsmoment 2,4Nm. Ik max:4.5 KA.Utløsergrense 30/100mA. Støtstrømsikker 250A(8/20). UN 400V.Trippindikator hvit/blå.B/C/D karakteristikk.
Product codes
Basic information
Technical specifications
Documents (2)
| SAP | GBW214 |
|---|---|
| PLC | 1654851 |
| STK | 1654851 |
| GTIN/EAN | 4015081185108 |
| Manufacturer part number | 120680 |
| Vendor material number | 1654851 |
| Package measurements (L x W x H) | 80 x 70 x 73 mm |
| Package volume | 0.409 l |
| Package weight | 0.48 kg |
| Package units | 1 / 1 |
| Usage quantity | – |
| UNSPSC | 39121614 |
| Brand | EATON |
| Ambient temperature during operating | -25 ... 40 °C |
| Anti-nuisance tripping version | false |
| Built-in depth | 70 mm |
| Concurrently switching neutral conductor | true |
| Connectable conductor cross section multi-wired | 1 ... 25 mm² |
| Connectable conductor cross section solid-core | 1 ... 25 mm² |
| Current limiting class | 3 |
| Degree of protection (IP) | IP20 |
| Frequency | 50 Hz |
| Leakage current type | A |
| Number of poles (total) | 4 |
| Number of protected poles | 4 |
| Over voltage category | 3 |
| Pollution degree | 2 |
| Rated current | 25 A |
| Rated fault current | 0.1 A |
| Rated impulse withstand voltage Uimp | 4 kV |
| Rated insulation voltage Ui | 500 V |
| Rated short-circuit breaking capacity Icn according to EN 61009-1 | 4.5 kA |
| Rated short-circuit breaking capacity according to EN 60898 | 4.5 kA |
