hager Knx persienneaktor 4 k 24v mod txa226 hager

KNX PERSIENNEAKTOR 4 K 24V MOD TXA226 HAGER

Product number
4500209
KNX PERSIENNEAKTOR 4K 24V MOD
KNX PERSIENNEAKTOR 4 KANAL 24V MODULÆR Norm: EN 60669-1 EN 60669-2-1 EN 50090-2-2, 30V DC systemspenning, 230V ~50/60 Hz, Eget forbruk 2 W, IP 30, Driftstemperatur 0ºC - +45ºC, Applikasjonsprogram TL226B V_2.0, programmeres med TX100 eller ETS, WAGO Quick Connect tilkoblingsklemme, manuell betjening direkte på produkt, LED indikering av koblingstilstand
Product codes
Basic information
Technical specifications
Documents (2)
SAPGBU224
PLC4500209
STK4500209
GTIN/EAN3250616049611
Manufacturer part numberTXA226
Vendor material number4500209
Package measurements (L x W x H)69 x 71 x 90 mm
Package volume0.441 l
Package weight0.22 kg
Package units1
Usage quantity1
UNSPSC39121107
BrandHAGER
Bus system KNXtrue
Bus system KNX radiofalse
Bus system LONfalse
Bus system Powernetfalse
Bus system radio frequentfalse
Degree of protection (IP)IP20
Local operation/hand operationtrue
Max. number of venetian-blind outputs4
Max. switching power1380 W
Mounting methodDRA (DIN-rail adapter)
Number of inputs0
Other bus systemsTebis TX
Radio frequent bidirectionalfalse
Switching current (resistive)6 A
Type of currentDC
Width in number of modular spacings4
With LED indicationtrue
With bus connectiontrue
With switch functionfalse
