Lastbryter IS404 63
Product number
1623586
IS404, 4 pol, 63A, Smissline
Lastbryter
Product details
Technical specifications
Version as main switchyes
Version as maintenance-/service switchno
Version as safety switchno
Version as emergency stop installationno
Version as reversing switchno
Number of switches4
Max. rated operation voltage Ue AC0 V
Rated operating voltage230 - 400 V
Rated permanent current Iu63 A
Rated permanent current at AC-23, 400 V63 A
Rated permanent current at AC-21, 400 V63 A
Rated short-time withstand current lcw1.5 kA
Number of poles4
Motor drive optionalno
Motor drive integratedno
Product codes
SAPDJX172
El number1623586
Product number1623586
GTIN/EAN7612270104390
Manufacturer part number2CCF544160E0630
Vendor material number2CCF544160E0630
Basic information
Package measurements (L x W x H)75 x 72 x 91 mm
Package volume0.491 l
Package weight0.38 kg
Base uniteach
Package units1
Usage quantity–
UNSPSC32000000
BrandABB
Country of OriginIT Italy
Customs tariff code85362000
