PLS PM5082-T-2ETH
Product number
4541579
CPU eCo Pro,DI:12/DO:8/DC:2
PM5082-T-2ETH: AC500-eCo Processor module. Memory 8MB. 12 DI 24VDC. 8 DO 24VDC 0.5A. 2 DC 24VDC. 2 Ethernet interfaces. 3 option slots.
Product details
Technical specifications
Supply voltage DC20.4 - 28.8 V
Voltage type (supply voltage)DC
ModelCompact
Number of digital inputs12
Number of digital outputs8
Type of memoryRAM
Memory size9100 kByte
SIL according to IEC 61508None
Performance level according to EN ISO 13849-1None
Explosion safety category for gasNone
Explosion safety category for dustNone
Width82 mm
Height135 mm
Depth74 mm
Product codes
SAPDFQ719
El number4541579
Product number4541579
GTIN/EAN4013614570988
Manufacturer part number1SAP124600R0173
Vendor material number1SAP124600R0173
Basic information
Package measurements (L x W x H)74 x 82 x 135 mm
Package volume0.819 l
Package weight0.265 kg
Base uniteach
Package units1
Usage quantity–
UNSPSC32000000
BrandABB
Country of OriginDE Germany
Customs tariff code85389000
