SURGE ARRESTER FOR HOUSEHOLD DG TT 5 275
Product number
1606051
Overspenningsvern Type 2 TNS kompakt
DEHNGuard. Mellomvern TT/TN-S 275 M 3+1 beskyttelse. Kompakt
Product details
Technical specifications
System configuration TNyes
System configuration TN-C-Syes
System configuration TN-Syes
System configuration TTyes
Number of conductors (without earthing)4
Nominal discharge surge current (8/20)20 kA
Max. discharge surge current (8/20)40 kA
Nominal voltage AC230 V
Max. continuous voltage AC275 V
Voltage protection level1.5 kV
Voltage protection level L-N1.5 kV
Voltage protection level N-PE1.5 kV
Max. overcurrent protection device, parallel connection (fuse)63 A
Max. overcurrent protection device, series connection (fuse)63 A
Short-circuit breaking capacity (Isccr)6 kA
Product codes
SAPDLT540
El number1606051
Product number1606051
GTIN/EAN4013364157996
Manufacturer part number900455
Vendor material number900455
Basic information
Package measurements (L x W x H)38 x 105 x 76 mm
Package volume0.303 l
Package weight0.143 kg
Base uniteach
Package units1
Usage quantity–
UNSPSC39121634
BrandDEHN
Country of OriginDE Germany
Customs tariff code85363000
