Potensialutjevnings- skinne 12
Product number
1211502
Potensialutjevningsskinne 12
Industriskinne med 12 koblinger 505x40x5 mm Skruer M10x25mm. Cu
Product details
Technical specifications
Construction typeSurface mounting fix
ModelWithout covering cap
Insulatoryes
Explosion-tested versionyes
Height40 mm
Width40 mm
Length505 mm
Number of connections conductor to 6 mm² fixed12
Number of connections conductor to 16 mm² fixed12
Number of connections conductor to 25 mm² fixed12
Number of connections conductor to 95 mm² fixed12
Material of contact railCopper
Surface of the contact railUntreated
Material of clampCopper
Surface of the clampUntreated
Product codes
SAPDIK457
El number1211502
Product number1211502
GTIN/EAN4013364096448
Manufacturer part number472237
Vendor material number472237
Basic information
Package measurements (L x W x H)505 x 70 x 40 mm
Package volume1.414 l
Package weight1.54 kg
Base uniteach
Package units1
Usage quantity–
UNSPSC32000000
BrandDEHN
Country of OriginDE Germany
Customs tariff code85363000
