INTERMEDIATE RELAY XPOLE Z-R230/16-20
Product number
4100202
Installation relay, 230 V AC, 2NO, 16A
Installation relay with manual operation, control voltage 230V AC, function: 2 NO, rated operational current 16 A, 240V AC, type conform to IEC/EN 60947-4-1, standard front dimension 45 mm, mounting width 1 MU, top-hat rail mounting.
Product details
Technical specifications
FunctionMechanical
Mounting methodDIN rail
Width in number of modular spacings1
Built-in depth60 mm
Number of contacts as normally open contact2
Number of contacts as normally closed contact0
Number of contacts as change-over contact0
Control voltage 1196-250 V
Type of control voltage 1AC
Frequency control voltage 150-60 Hz
Control voltage 20 - 0 V
Type of control voltage 2AC
Frequency control voltage 20 - 0 Hz
Rated current16 A
Supply voltage240-240 V
Product codes
SAPCHX210
El number4100202
Product number4100202
GTIN/EAN9010238026988
Manufacturer part numberICS-R16A230B200
Vendor material number4100202
Basic information
Package measurements (L x W x H)95 x 75 x 30 mm
Package volume0.214 l
Package weight0.2 kg
Base uniteach
Package units1 / 2 / 2
Usage quantity–
UNSPSC39121529
BrandEATON
Customs tariff code85364900
