ØLFLEX® CLASSIC 130 H 3G0,75
Product number
1070916
ØLFLEX® CLASSIC 130 H 3G0,75
Halogenfri uskjermet styrekabel for industriellt innendørs bruk, uten indre kappe.
Product details
Technical specifications
Conductor materialCopper
Conductor surfaceBare
AWG size20
Nominal cross section conductor0.75 mm²
Conductor categoryClass 5 = flexible
Conductor resistance at 20 °C26 Ohm/km
Number of cores3
Screen over stranding elementNone
Stranding elementNo
Screen over strandingNone
Material core insulationOther
Specification core insulationOther
Core identification according to HD 308 S2no
Core identificationNumbers
With protective conductoryes
Product codes
SAPCEK862
El number1070916
Product number1070916
GTIN/EAN4044773746556
Manufacturer part number1123033
Vendor material number1123033
Basic information
Package measurements (L x W x H)1000 x 5.8 x 5.8 mm
Package volume0.034 l
Package weight0.056 kg
Base unitm
Package units1 / 500
Usage quantity–
UNSPSC26121500
BrandLAPP KABEL
Country of OriginFR France
Customs tariff code85444921
