ØLFLEX® CLASSIC 135 CH 4G2,5
Product number
1071238
ØLFLEX® CLASSIC 135 CH 4G2,5
Halogenfri skjermet styrekabel for industriellt innendørs bruk, uten indre kappe.
Product details
Technical specifications
Conductor materialCopper
Conductor surfaceBare
AWG size14
Nominal cross section conductor2.5 mm²
Conductor categoryClass 5 = flexible
Conductor resistance at 20 °C7.98 Ohm/km
Number of cores4
Screen over stranding elementNone
Stranding elementNo
Screen over strandingBraiding
Material core insulationOther
Specification core insulationOther
Core identification according to HD 308 S2no
Core identificationNumbers
With protective conductoryes
Product codes
SAPCEL048
El number1071238
Product number1071238
GTIN/EAN4044773747423
Manufacturer part number1123342
Vendor material number1123342
Basic information
Package measurements (L x W x H)1000 x 10 x 10 mm
Package volume0.1 l
Package weight0.201 kg
Base unitm
Package units1
Usage quantity–
UNSPSC26121500
BrandLAPP KABEL
Country of OriginFR France
Customs tariff code85444921
