BETATHERM 145 35MM2 SVART
Product number
1012230
BETAtherm 145 35mm2 Svart
Enleder med DNV-GL, Lloyds Register, Bureau Veritas, CCS og GHOST R godkjenning. Tverrbundet (cross-linked) isolasjon ved bestråling gjør den svært godt egnet for bruk ved både høye og lave temperaturer. Halogenfri og flammehemmende med lav røykutvikling og ingen korrosive eller giftige gasser (NF X 70-100). Enkel avisolering og fortinnede fintrådete ledere (klasse 5) gjør den godt egnet for lodding. Spesielt tilpasset skip og offshore installasjon.
Product details
Technical specifications
Conductor materialCopper
Conductor surfaceTinned
Nominal cross section conductor35 mm²
Diameter conductor10.1 mm
Conductor categoryClass 5 = flexible
Conductor resistance at 20 °C0.565 Ohm/km
Number of cores1
Twisted coresno
Material core insulationPolyolefin
Specification core insulationOther
Core identification according to HD 308 S2no
Core identificationColour
Core colourBlack
With protective conductorno
Max. permitted conductor temperature145 °C
Product codes
SAPCEK728
El number1012230
Product number1012230
GTIN/EAN4044774132624
Manufacturer part number83087201
Vendor material number83087201
Basic information
Package measurements (L x W x H)1000 x 11 x 11 mm
Package volume0.121 l
Package weight0.349 kg
Base unitm
Package units1
Usage quantity–
UNSPSC26121500
BrandLAPP KABEL
Country of OriginCH Switzerland
Customs tariff code85444921
Sustainability info
Global Warming Potential (GWP)
GWP value for A1– A32.2336
GWP unitm
Data source for GWPco2data.fi
ID from emition database7000000480
