BETATHERM 145 6,0MM2 SVART
Product number
1012185
BETAtherm 145 6,0mm2 Svart
Enleder med DNV-GL, Lloyds Register, Bureau Veritas, CCS og GHOST R godkjenning. Tverrbundet (cross-linked) isolasjon ved bestråling gjør den svært godt egnet for bruk ved både høye og lave temperaturer. Halogenfri og flammehemmende med lav røykutvikling og ingen korrosive eller giftige gasser (NF X 70-100). Enkel avisolering og fortinnede fintrådete ledere (klasse 5) gjør den godt egnet for lodding. Spesielt tilpasset skip og offshore installasjon.
Product details
Technical specifications
Conductor materialCopper
Conductor surfaceTinned
Nominal cross section conductor6 mm²
Diameter conductor4.7 mm
Conductor categoryClass 5 = flexible
Conductor resistance at 20 °C3.39 Ohm/km
Number of cores1
Twisted coresno
Material core insulationPolyolefin
Specification core insulationOther
Core identification according to HD 308 S2no
Core identificationColour
Core colourBlack
With protective conductorno
Max. permitted conductor temperature145 °C
Product codes
SAPCEK581
El number1012185
Product number1012185
GTIN/EAN4044774132952
Manufacturer part number83087141
Vendor material number83087141
Basic information
Package measurements (L x W x H)1000 x 5 x 5 mm
Package volume0.025 l
Package weight0.065 kg
Base unitm
Package units100
Usage quantity–
UNSPSC26121500
BrandLAPP KABEL
Country of OriginCH Switzerland
Customs tariff code85444921
Sustainability info
Global Warming Potential (GWP)
GWP value for A1– A30.416
GWP unitm
Data source for GWPco2data.fi
ID from emition database7000000480
