ÖLFLEX CLASSIC 115 CY 4G0,75 BK
Product number
1025146
CLASSIC 115 CY 4G0,75 BK
Skjermet PVC kontrollkabel med liten ytre diameter og sort ytterkappe. UV og værbestandig i h.h.t. ISO 4892-2. Kabelen kan brukes innen- og utendørs
Egnet for utendørs installasjoner. Sorte ledere med hvit nummerering i h.h.t. VDE 0293-334.
Norm: Basert på EN 50525-2-52
Product details
Technical specifications
Conductor materialCopper
Conductor surfaceBare
Nominal cross section conductor0.75 mm²
Conductor categoryClass 5 = flexible
Conductor resistance at 20 °C26 Ohm/km
Number of cores4
Screen over stranding elementNone
Stranding elementNo
Screen over strandingBraiding
Material core insulationPolyvinyl chloride (PVC)
Specification core insulationOther
Core identification according to HD 308 S2no
Core identificationNumbers
With protective conductoryes
Drain wireno
Product codes
SAPDFI561
El number1025146
Product number1025146
GTIN/EAN4044776969617
Manufacturer part number1136111
Vendor material number1136111
Basic information
Package measurements (L x W x H)1000 x 7 x 7 mm
Package volume0.049 l
Package weight0.095 kg
Base unitm
Package units1 / 500
Usage quantity–
UNSPSC32000000
BrandLAPP KABEL
Country of OriginFR France
Customs tariff code85444921
