SKINTOP®MS-SC NIPPEL EMC M50 27,0-35,0
Product number
1247766
SKINTOP®MS-SC-M 50X1,5
SKINTOP®MS-SC-Metriske gjenger-IP68,5 bar-EMC nippel med innebygget strekkavlastning i forniklet messing - med O-ring - Neoprene pakning - -30 til + 100 ºC
Product details
Technical specifications
Thread typeMetric
Nominal thread size metric/PG50
Nominal thread size inch/gas pipe threadOther
Pitch thread1.5 mm
Thread length10 mm
Wrench width54 mm
Hexagon angular dimension59 mm
Suitable for cable diameter27 - 35 mm
MaterialMetal
Material qualityBrass
Surface protectionNickel-plated
Halogen freeno
Glass-fibre reinforcedno
Degree of protection (IP)IP68
Shock resistantyes
Product codes
SAPCDR796
El number1247766
Product number1247766
GTIN/EAN4044773170450
Manufacturer part number53112670
Vendor material number53112670
Basic information
Package measurements (L x W x H)60 x 60 x 60 mm
Package volume0.216 l
Package weight0.243 kg
Base uniteach
Package units1
Usage quantity–
UNSPSC39121311
BrandLAPP KABEL
Country of OriginDE Germany
Customs tariff code74199900
Documents (4)
Sustainability info
Global Warming Potential (GWP)
GWP value for A1– A31.9849
GWP uniteach
Data source for GWPEandoX
