LIGHTNING CONTROLLER V25-B/O
Product number
1658595
V25-B/0-280V
V25-B+C/0 - 280 V. Utskiftbar patron 1 polt.
Kan skiftes uten verktøy og spenningsavbrudd.
Product details
Technical specifications
System configuration DCno
System configuration ITno
System configuration TNyes
System configuration TN-Cyes
System configuration TN-C-Syes
System configuration TN-Syes
System configuration TTyes
System configuration otheryes
Number of poles1
Lightning impulse current (10/350 µs)7 kA
Max. continuous voltage AC280 V
Max. continuous voltage DC350 V
Nominal voltage AC230 V
Nominal voltage DC230 V
Max. PV-voltage350 V
Product codes
SAPABM994
El number1658595
Product number1658595
GTIN/EAN4012195394099
Manufacturer part number5097053
Vendor material number1658595
Basic information
Package measurements (L x W x H)45 x 30 x 17.5 mm
Package volume0.024 l
Package weight0.095 kg
Base uniteach
Package units1
Usage quantity–
UNSPSC39121621
BrandOBO BETTERMANN
Country of OriginHU Hungary
Customs tariff code85363000
