PT 4-Twin-PE rekkeklemme innstikk 0,14-2,5
Product number
1264955
PTTB 2,5-DIO/U-O
Byggelementrekkeklemme, med integrert diode 1N4007, nominell spenning: 500 V, nominell strøm: 0,5 A, tilkoblingstype: Innstikkstilkobling, antall tilkoblinger: 4, tverrsnitt:0,14 mm² - 4 mm², AWG: 26 - 12, bredde: 5,2 mm, farge: grå, monteringstype: NS 35/7,5, NS 35/15
Product details
Technical specifications
Explosion-tested version 'Ex e'no
Connectable conductor cross section fine-strand without cable end sleeve0.14 - 4 mm²
Connectable conductor cross section fine-strand with cable end sleeve0.14 - 2.5 mm²
Connectable conductor cross section solid-core0.14 - 4 mm²
Connectable conductor cross section multi-wired0.14 - 2.5 mm²
Rated current In0.5 A
Rated voltage500 V
Type of electrical connection 1Other
Type of electrical connection 2Push-in clamp connection
Number of levels2
Number of clamp positions per level2
Internally connected stagesno
Mounting methodDIN rail (top hat rail) 35 mm
Material insulation bodyThermoplastic
Operating temperature-60 - 105 °C
Product codes
SAPGBZ602
El number1264955
Product number1264955
GTIN/EAN4046356419031
Manufacturer part number3210936
Vendor material number3210936
Basic information
Package measurements (L x W x H)68 x 5 x 48 mm
Package volume0.016 l
Package weight0.012 kg
Base uniteach
Package units1
Usage quantity1
UNSPSC39121432
BrandPHOENIX
Country of OriginPL Poland
Customs tariff code85369090
