STRØMLIST 230V 8XSCHUKO M/BRYT VDIG162731
Product number
6993684
Actassi 19" strømlist 1U 8 x schuko 230 V 16 A stikkontakter, med bryter
19’’ strømlist 16A/250V i 1U, ALU eloksert. 2-polet m/jord 16A/3680W, AC250V, IP20, farge RAL7016, Plast: PA6 GF30. Leveres med 3 m lang strømledning og med merkevindu for merking....
Product codes
Basic information
Technical specifications
Documents (3)
| SAP | GBV562 |
|---|---|
| PLC | 6993684 |
| STK | 6993684 |
| GTIN/EAN | 3606485133997 |
| Manufacturer part number | VDIG162731 |
| Vendor material number | VDIG162731 |
| Package measurements (L x W x H) | 160 x 520 x 55 mm |
| Package volume | 4.576 l |
| Package weight | 1.3 kg |
| Package units | 1 / 11 |
| Usage quantity | 1 |
| UNSPSC | 32000000 |
| Brand | SCHNEIDER |
| Angle rotated central insert | 35° |
| Colour | Grey |
| Core cross section | 1.5 mm² |
| Degree of protection (IP) | IP20 |
| Halogen free | true |
| Housing shape | Rectangular |
| Length of power cord | 3 m |
| Mains filter | false |
| Material | Plastic |
| Material quality | Thermoplastic |
| NEMA designation | None |
| Nominal current | 16 A |
| Number of CEE socket outlets | 8 |
| Number of Euro socket outlets | 0 |
| Number of NEMA-outlets | 0 |
| Number of USB connections | 0 |
| Number of cold device socket outlets | 0 |
| Number of other socket outlets | 0 |
| Number of socket outlets Type P11 (Italy) | 0 |
| Number of socket outlets type Bipasso (Italy) | 0 |
