IND.GIV.40X40X117 20MM NPN SL XS8C4A1NCP20
Product number
4318845
Induktiv givere 40x40x117mm Sn=20mm NPNNONC
Induktiv givere format rektangulær størrelse 40x40x117mm føleavstand Sn=20mm utgang NPN NO/NC kontakt
Product details
Technical specifications
Width sensor117 mm
Height of sensor40 mm
Length of sensor40 mm
Diameter sensor0 mm
Mechanical mounting condition for sensorConcise
Switching distance20 mm
Suitable for safety functionsno
Type of switch functionOther
Type of switching outputNPN/NPN
Type of electric connectionScrew connection
Number of semiconductor outputs with signalling function2
Number of contact energized outputs with signalling function0
Number of protected semiconductor outputs2
Number of protected contact energized outputs0
Type of actuationMetallic Target
Product codes
SAPGCN622
El number4318845
Product number4318845
GTIN/EAN3666916010341
Manufacturer part numberXS8C4A1NCP20
Vendor material numberXS8C4A1NCP20
Basic information
Package measurements (L x W x H)50 x 50 x 145 mm
Package volume0.363 l
Package weight0.244 kg
Base uniteach
Package units1
Usage quantity1
UNSPSC39121550
BrandTELEMECANIQUE
Country of OriginNO Norway
Customs tariff code85364900
