TRYKKTR.DIS.40BAR 0-10V 1 PNP
Product number
4306354
Trykktransmitter display 40Bar 24VDC 0-10V 1 PNP
Trykktransmitter display 40Bar 24VDC analog utgang 0-10V og 1 utgang PNP M12 og vaesketilslutning G1/4"
Product details
Technical specifications
Suitable as guardyes
Suitable as 2-point controllerno
Suitable as limiterno
Engaging pressure2 - 40 bar
Initial setting0 - 40000 hPa
Switch off pressure3.2 - 40 bar
End setting0 - 40000 hPa
Pressure-switching differential1.2 bar
Max. test pressure150 bar
Bursting pressure150 bar
Medium temperature-20 - 80 °C
Thread sizeOther
Rated voltage Ue at DC24 - 24 V
Initial value measuring range pressure200000 Pa
End value measuring range pressure4000000 Pa
Product codes
SAPCCL561
El number4306354
Product number4306354
GTIN/EAN3666916020708
Manufacturer part numberXMLR040G1P75
Vendor material numberXMLR040G1P75
Basic information
Package measurements (L x W x H)75 x 127 x 65 mm
Package volume0.619 l
Package weight0.181 kg
Base uniteach
Package units1
Usage quantity–
UNSPSC41112410
BrandTELEMECANIQUE
Country of OriginCH Switzerland
Customs tariff code90322000
