OVERSPENNINGSVERN VPU AC II 4 350/50 KA
Product number
1224469
OVERSPENNINGSVERN VPU AC II 4
Overspenningsvern VPU AC II 4 350/50 kA
Product details
Technical specifications
System configuration DCno
System configuration ITno
System configuration TNyes
System configuration TN-Cno
System configuration TN-C-Syes
System configuration TN-Syes
System configuration TTno
Number of conductors (without earthing)4
Nominal discharge surge current (8/20)20 kA
Max. discharge surge current (8/20)20 kA
Nominal voltage AC230 V
Max. continuous voltage AC350 V
Short-circuit breaking capacity (Isccr)50 kA
Integrated short-circuit protectionyes
Integrated backup fuseno
Product codes
SAPDCI233
El number1224469
Product number1224469
GTIN/EAN4050118599817
Manufacturer part number2591120000
Vendor material number2591120000
Basic information
Package measurements (L x W x H)513 x 111 x 82 mm
Package volume4.669 l
Package weight0.513 kg
Base uniteach
Package units1
Usage quantity–
UNSPSC39121610
BrandWEIDMÜLLER
Country of OriginSI Slovenia
Customs tariff code85363000
