REKKEKLEMME WDU 2,5 ZR BLÅ WEIDMÜLLER
Product number
1268932
WDU 2,5 ZR BLÅ Gjennomgangsklemme, Merketverrsnitt: 2.5 mm², Tilkoblingstype: Skru tilkobling, Isolasjonsmateriale: Wemid, Farge på Isolasjonsmateriale: Blå, Installasjon: TS 35
Product details
Technical specifications
Connectable conductor cross section fine-strand without cable end sleeve0.5 - 4 mm²
Connectable conductor cross section fine-strand with cable end sleeve0.5 - 2.5 mm²
Connectable conductor cross section solid-core0.5 - 4 mm²
Connectable conductor cross section multi-wired1.5 - 4 mm²
Rated current In24 A
Rated voltage800 V
Type of electrical connection 1Screw connection
Type of electrical connection 2Screw connection
Number of levels1
Number of clamp positions per level3
Suitable for conductor materialCopper
Mounting methodDIN rail (top hat rail) 35 mm
Material insulation bodyThermoplastic
Operating temperature-50 - 120 °C
Width5.1 mm
Product codes
SAPGAI794
El number1268932
Product number1268932
GTIN/EAN4008190173586
Manufacturer part number1024780000
Vendor material number1024780000
Basic information
Package measurements (L x W x H)0 x 0 x 0 mm
Package volume0.001 l
Package weight0.1 kg
Base uniteach
Package units100
Usage quantity1
UNSPSC39121432
BrandWEIDMÜLLER
Country of OriginCZ Czech Republic
Customs tariff code85369010
