ZTR 2,5/3 AN SKILLEKLEMME
Product number
1209313
ZTR 2.5/3AN Skille/Måleklemme, Merketverrsnitt: 2.5 mm², Tilkoblingstype: Fjærklemme tilkobling, Isolasjonsmateriale: Wemid, Farge på Isolasjonsmateriale: Beige, Installasjon: TS 35, For tre tilkoblinger
Product details
Technical specifications
Connectable conductor cross section fine-strand without cable end sleeve0.5 - 4 mm²
Connectable conductor cross section fine-strand with cable end sleeve0.5 - 2.5 mm²
Connectable conductor cross section solid-core0.5 - 4 mm²
Connectable conductor cross section multi-wired0.5 - 4 mm²
Rated current In20 A
Rated voltage500 V
Type of electrical connection 1Spring clamp connection
Number of levels1
Number of clamp positions per level3
Internally connected stagesno
Mounting methodDIN rail (top hat rail) 35 mm
Material insulation bodyThermoplastic
Operating temperature-50 - 120 °C
Width5.1 mm
Height79.5 mm
Product codes
SAPGBI461
El number1209313
Product number1209313
GTIN/EAN4032248404902
Manufacturer part number8731720000
Vendor material number8731720000
Basic information
Package measurements (L x W x H)0 x 0 x 0 mm
Package volume0.001 l
Package weight0.02 kg
Base uniteach
Package units50
Usage quantity1
UNSPSC39121432
BrandWEIDMÜLLER
Country of OriginCZ Czech Republic
Customs tariff code85369010
